| Processing Range |
φ1.2-φ40mm
Max Length of Cut-in Mill150mm |
| Motor |
For Grinding Wheel5.5kW4P(7.5kW 4P)
For Guide Wheel0.4/0.2kW 4/8P
Hydraulic Pump (for Trimming Device)0.75kW 4P
For Water Pump0.18kW 2P |
| Specification of Grinding Wheel |
455×150×228.6mm(Outer Diameter×Width×Bore Diameter) |
| Specification of Guide Wheel |
305×150×177.8mm(Outer Diameter×Width×Bore Diameter) |
| Rotational Speed |
Grinding Wheel1400rpm(MAX.1880rpm)
Linear Speed33m/s(MAX.45m/s)
Variable-frequency Stepless Speed Regulation of Guiding Wheel15-165rpm |
| Tilting Angle of Guiding Wheel |
﹢6°-﹣1° |
| Floor Area |
2040×1500mm(Width×Length) |
| Machine Tool Weight |
About 2.5 t |
